The Jerry machine from the Hack The Box platform nicely illustrates the danger of weak and default credentials.
TL;DR
NodeZero obtained system-level privileges on Jerry by first finding weak administrative credentials to the Apache Tomcat Manager web application running on port 8080. Using those credentials, NodeZero abused built-in functionality within the Manager application to gain system-level shell access to the host.
Timeline of Notable Events
| Timestamp (UTC) | Event |
|---|---|
| 2021-09-15 17:22:04 PM | Assessment started |
| 2021-09-15 17:22:49 PM | Identified Apache Tomcat Manager application running on port 8080 |
| 2021-09-15 17:23:18 PM | Found weak credentials to the Manager application for the tomcat user |
| 2021-09-15 17:23:38 PM | Used the Manager application to upload a malicious war file, establishing a Metasploit reverse shell running as the NT AUTHORITY\SYSTEM user |
Attack Graph
This is the attack graph that represents what NodeZero did. A detailed walkthrough is provided below.
Walkthrough
17:22:04 PM UTC – NodeZero started the assessment. It was provided Jerry’s IP address, 10.10.10.95, and confirmed the machine was live with an nmap ping sweep.
NodeZero ran TCP and UDP port scans using nmap and found a single HTTP port open: 8080.
17:22:49 PM UTC – NodeZero crawled the website running on port 8080 and found the default landing page for Apache Tomcat. Apache Tomcat is a very popular web server used to run Java-based web applications.
NodeZero attempted to access the Manager application running within Tomcat but found that it required credentials to access.
17:23:18 PM UTC – NodeZero ran a default credentials scan using nmap and the nndefaccts script. It discovered that the Manager application could be accessed with the username tomcat and the password s3cret.
17:23:38 PM UTC – It is often the case that admin-level access to a web application results in obtaining shell access to the host running the web application. Attackers are well aware of different types of web applications and what kind of features they expose that can be abused to access the underlying host. This attacker technique—abusing admin-level web application privileges—is not really a vulnerability or misconfiguration; it’s simply the byproduct of having admin-level access in the first place.
The Manager application enables users to manage the lifecycle of Java web applications run by the Tomcat web server. Users can deploy new applications, start them, stop them, and undeploy them. An attacker can abuse this functionality to deploy a malicious Java application. The malicious Java application can be used to execute arbitrary code within the Tomcat process running on the host.
To deploy a Java application within Tomcat, it must be first packaged up as a WAR (Web Application Archive) file. WAR files are essentially zip files containing Java code that adhere to a standard format.
The Metasploit framework contains a module, exploit/multi/http/tomcat_mgr_upload, that automates the process of generating a malicious WAR file and uploading it to a Tomcat server, given the username and password for a valid user. NodeZero used this module to deploy a malicious Java application that connected back to its own host and gave it a reverse shell. Within that reverse shell, NodeZero executed commands on the target host. The whoami command showed that it was running as NT AUTHORITY\SYSTEM, meaning the machine was fully compromised through the single tomcat user credential.
A Note on Cleaning Up
Responsible pentesters try not to leave traces of their activity lying around. In the case of the Tomcat exploit run using Metasploit, it was important to NodeZero to undeploy the malicious Java application that had been deployed and executed. As part of doing this, it discovered that the Metasploit module used didn’t automatically undeploy the application, despite claiming to have done so. Upon further review, NodeZero noticed a bug in the Metasploit code related to the undeploy logic and submitted a patch to the Metasploit git repo to fix it.
Conclusion
NodeZero fully compromised the Jerry machine in less than two minutes. To do this, it took advantage of two critical security flaws:
- Weak administrative credentials for a web application
- The fact that this web application was running as an over-privileged SYSTEM-level user
These two flaws are unfortunately common and are routinely encountered in real-world environments. Simple mitigations include:
- Creating a dedicated low-privilege service account to run the application
- Setting up a strong password
